Mixer-Settler Specifications
Mixer-Settler Engineering Specs
Detailed specifications for our mixer-settler systems across pilot and commercial scales.
Pilot Plant Units
Fully integrated package systems for testing and development
Flow Rate100 ml/min — 75 GPM
ConfigurationSimplex, Duplex
MountingCommon structural steel frame
PipingAll interstage piping included
RecycleFull recycle provisions
MotorsExplosion-proof electric drive
Controls & InstrumentationOptional — VFD, controls, and instrumentation available
Commercial Units
Production-scale systems for full plant operations
Flow RateUp to 2,000 GPM
ConfigurationSimplex, Duplex, Triplex
pH HandlingNegative pH levels
MotorsExplosion-proof electric drive
Controls & InstrumentationConnections included (controls and instrumentation by others)
Fire ProtectionConnections for fire protection included
Materials
Construction Materials & Applications
| Material | Typical Applications |
|---|---|
| FRP (Fiberglass Reinforced Plastic) | General purpose, corrosion resistant, cost-effective |
| 316L Stainless Steel | Acidic environments, high-temperature applications |
| 316LSS | Copper recovery, corrosive process streams |
| Duplex Stainless Steel | High-strength, chloride-resistant environments |
| CPVC | Higher temperature chemical resistance, corrosive environments |
| PVDF | High-purity applications, excellent chemical and UV resistance |
| PVC | Cost-effective chemical resistance at moderate temperatures |
| Polypropylene | Lightweight, chemical resistant at moderate temperatures |
| PETG | 3D printed pilot plant models for rapid prototyping and testing |
| Custom Alloys | Specialized process chemistry requirements |
